960*960-B IP65 waterproof P10 P8 P5 LED display iron cabinet

Short Description:

1.Size :960*960mm*120mm

2.Module Size: 320*160mm 192*192mm

3.Weight: 18Kg

4.Color: black, blue

5.Installation way :fixed installation

6.Use Environment: outdoor

7.Accessory: fast lock, handle, power plate, received plate, connect plate.


Product Detail

Product Tags

Product information

Place of Origin Shenzhen,Guangdong, China
Model size 960*960*145mm
Brand Name RUICHEN
Tube Chip Color Full color
Display Function Video
Usage outdoor
Pixels P10mm/P 5mm/P 6.67mm/P8mm
Screen Dimension Custom Made
Module size 320*160 mm,192*192mm
Color black, blue, gray,white
Certificate ISO9001,CE
Application Advertising



Name

LED display waterproof cabinet

Material

Iron

Aluminium

Cabinet size

0.6

0.6

0.6

0.6

Plate thickness

1.0mm

1.2mm

1.0mm

1.2mm

1.5mm

1.8mm

1.5mm

1.8mm

Standard accessory

Power supply plate,received card plate,position pin,connector plate

Specification

Outdoor P10 LED Display
Model number P10
Pixel pitch 10mm
Module resolution 32*16 dots
Module size 320mm*160mm
Cabinet resolution 96*96 dots
Cabinet size 960mm*960mm
Pixel density 10000dots/sqm
LED configuration SMD3535
Module weight 0.5kg
Average consumption 700w/sqm
Best view distance 10m~200m
View angle 140º
Brightness 3500cd/sqm
Scanning 1/4scan
Refresh rate 800Hz
Frame frequency 360Hz
Max power consumption 1200w/sqm
Warranty 2years
Grey scale 16384
Working voltage 220VAC/50Hz±10%
Life span 100000hours
Lifetime to 50% brightness 75000hours
Working temperature 20to +60
Certification CCC/CE/RoHS

2eae5c80c81d81b2f8db858ce5e9e9d (1) 01e770b412450142ae658438e6768c8 12c66ee764442027a30a992c0549baf b1d4c08af9ebfaf648002a87440a431

Packaging & Delivery

There are mainly three types of packing way:

20210817144141

Delivery way

1. By sea:Maritime transportation is a way of transporting goods between ports in different countries and regions by sea lanes, and it is the most important mode of transportation in international trade.

sea

2. By air:Air transport has won a considerable market with its fast, safe, punctual and super-high efficiency, greatly shortening the delivery time, and greatly promoting the logistics supply chain to speed up the capital turnover and circulation.

air

3.By express: TNT/UPS/DHL/FEDEX,It is more convenient and quick,It is mainly used for transporting goods with small volume and light weight.

interExpress

Shipping port:shenzhen /guangzhou/tianjin port.

Shipping term:EXW term、FOB term、CIF term

Payment types: T/T transfer,Weston union
