outdoor LED poster cabinet 960*1920 advertising machine screen
Quick Details
| Application | advertising |
| Color | Full Color |
| Panel Size | 960*1920mm |
| Pixel Pitch | 3mm |
| Place of Origin | Guangdong, China (Mainland) |
| Model Number | LK outdoor |
| Brand Name | RUICHEN |
| Module size | 192*192mm |
| Module resolution | 64*64 pixels |
| LED type | SMD1921 Nationstar |
| LED color | RGB |
| Color depth | 64 billion colors |
| Brightness | 5500cd/m2 |
| Contrast ratio | 5000:1 |
| Refresh rate | 1920~3840Hz |
| Frame rate | 60Hz |
| Driving IC | ICN2038 |
Specification
| Product model | LK outdoor |
| Pixel pitch | 3mm |
| Module size | 192*192mm |
| Module resolution | 64*64 pixels |
| Panel size | 960*1920mm |
| Panel resolution | 320*640 pixels |
| LED type | SMD1921 Nationstar |
| LED color | RGB |
| Color depth | 64 billion colors |
| Brightness | 5500cd/m2 |
| Contrast ratio | 5000:1 |
| Lifetime | 100000 hours |
| MBTF | 5000 hours |
| refresh rate | 1920~3840Hz |
| Frame rate | 60 Hz |
| Driving IC | ICN2038 |
| Scan | 1/16 scans |
| Viewing angle | 160o/160o |
| Gray Scale | 14 bits |
| receiving card | A5S |
| Max power (W/m2) | 960 |
| Ave power (W/m2) | 320 |
| Power input | 110VAC~240VAC |
| Working Temperature(℃) | -20°C～60°C |
| Working Humidity | 10%~95% |
| Storage Temperature( ℃) | -20°C～50°C |
| Storage Humidity | 10%~95% |
| Ingress protection | IP65/IP54 |
| Maintenance | Rear service |
| Cabinet material | Aluminum |
| Weight | 65kg |
| Warranty | 2 years |
|
Outdoor LED Poster Display |
||||||
| Pixel Pitch | Display size(mm) | Cabinet size(mm) | Led lamp | Resolution(dots/m2) | Scan | Brightness(cd/m2） |
| P4 | 512*1024mm | 572*1124*120mm | SMD2727/1921 | 62500 | 1/8 | >=5500 |
| P4 | 768*1280mm | 828*1380*120mm | SMD2727/1921 | 62500 | 1/8 | >=5500 |
| P4 | 768*1536mm | 828*1636*120mm | SMD2727/1921 | 62500 | 1/8 | >=5500 |
| P5 | 640*1600mm | 700*1700*120mm | SMD2727/1921 | 40000 | 1/8 | >=5500 |
| P5 | 640*1920mm | 700*2020*120mm | SMD2727/1921 | 40000 | 1/8 | >=5500 |
| P6 | 768*1536mm | 828*1636*120mm | SMD2727/1921 | 27777 | 1/8 | >=5500 |
Customer’s Review
Packaging & Delivery
There are mainly three types of packing way:
Delivery way
1. By sea:Maritime transportation is a way of transporting goods between ports in different countries and regions by sea lanes, and it is the most important mode of transportation in international trade.
2. By air:Air transport has won a considerable market with its fast, safe, punctual and super-high efficiency, greatly shortening the delivery time, and greatly promoting the logistics supply chain to speed up the capital turnover and circulation.
3.By express: TNT/UPS/DHL/FEDEX,It is more convenient and quick,It is mainly used for transporting goods with small volume and light weight.
Shipping port:shenzhen /guangzhou/tianjin port.
Shipping term:EXW term、FOB term、CIF term
Payment types: T/T transfer，Weston union
